BASELIT RGB S16 LIGHTSABER OPERATION MANUAL V1.1



BASELIT RGB S16 LIGHTSABER OPERATION MANUAL V1.1

Before reading this guide, make sure your lightsaber is a single-button or dual-button version. Note that lightsabers generally have three states, off, standby, and active.

Standby mode is while your saber is on (accepting inputs) but the blade is not active. Active mode is when your saber blade is lit (the LED is active) and making sound (if enabled).

ONE BUTTON OPERATION

WHILE BLADE IS IN STANDBY MODE

1.1.1 Wake up:

Press and hold until the button light is on to enter standby mode.

1.1.2 Power On:

Tap the button.

1.1.3 Adjust volume (3 modes):

Press and hold until the breath indicator flashes once, then release.

1.1.4 Change sound fonts:

Press and hold until the breath light blinks twice, then release.

1.1.5 Change BGM (3 types):

Hold until the breath light blinks three times, then release.

1.1.6 FOC off/on:

Hold until the breath light blinks four times, then release.

1.1.7 Motion Control On/Off:

Hold until the breath light blinks five times, then release.

1.1.8 Power save mode:

Press and hold until the backlight turns off (no operation for 10 minutes).

WHILE BLADE IS ACTIVE

1.2.1 Blaster:

Tap the button.

1.2.2 Lock:

Hold the button until the breath light flashes once, then release.

1.2.3 Color Change:

Hold until the breath light blinks twice, then release. Tap the button to exit this mode.

1.2.4 Change Blade Effects:

Hold the button until the breath light blinks three times, then release.

1.2.5 Turn Off:

Hold the button until the breath light flashes four times, then release.

GESTURE OPERATION IN STANDBY MODE

1.3.1 Turn on:

Twist the saber.

1.3.2 Change sound fonts:

With the blade up, hold the button, then twist the saber.

1.3.3 Change BGM:

With the blade down, hold the button, then twist the saber.

GESTURE OPERATION IN ACTIVE MODE

1.4.1 Turn off:

Twist the saber.

1.4.2 Switch Blade Effects:

When blade is up, hold the button, then twist the saber.

1.4.3 Change Color:

With the blade down, hold the button, then twist the saber.

1.4.4 FOC:

Strike the saber.

TWO BUTTON OPERATION

PWR Button: Main Button, Power Button.

AUX Button: Auxiliary Button, Function Button.

(When the buttons are distributed up and down: Upper button is the main button, lower button is the AUX button; When the buttons are distributed left and right: Left button is the main button, right button is the AUX button)

WHILE BLADE IS IN STANDBY MODE

Beeps when batteries are properly installed.

Beeps when charging properly.

2.1.1 Power On:

Tap the PWR button.

2.1.2 To change sound fonts:

Tap the AUX button.

2.1.3  Adjust volume:

Press and hold the PWR button, then release (mute/low volume/high volume).

2.1.4 Power save mode:

No operation for 20 minutes.

WHILE BLADE IS ACTIVE

2.2.1 Power off:

Tap the PWR button.

2.2.2 Blaster:

Tap the AUX button.

2.2.3 Lock:

Press and hold the AUX button, then release.

2.2.4 FOC Off/On:

Hold and release the PWR button.

GESTURE OPERATION IN STANDBY MODE

2.3.1 Power on: Rotate the saber.

2.3.2 Change sound fonts: With the blade up, hold the AUX button, then twist the saber.

2.3.3 Change BGM: With the blade down, hold the AUX button, then twist the saber

GESTURE OPERATION IN ACTIVE MODE

2.4.1 Turn off:

Twist the saber.

2.4.2 Switch Blade Effects:

With the blade up, hold the AUX button, then twist the saber.

2.4.3 Change Color:

With the blade down, hold the AUX button, then twist the saber.

2.4.4 FOC:

Hit the saber.
